Goodman 4.0 Ton 15.2 SEER2 R-32 Single-Stage Split Air Conditioner (GLXS5BA4810)
The Goodman 4.0 Ton 15.2 SEER2 R-32 Split Air Conditioner (GLXS5BA4810) is engineered for powerful cooling, energy efficiency, and long-term performance. Utilizing R-32 refrigerant, this unit offers eco-friendly climate control while reducing energy consumption.
With a 15.2 SEER2 rating, the Goodman 4.0 Ton SEER2 AC provides steady cooling, cost-effective operation, and optimal indoor comfort. Its single-stage cooling technology delivers consistent airflow and precise temperature control, making it an excellent choice for residential and light commercial applications.
Key Features:
✔ 15.2 SEER2 Efficiency: Maximizes cooling performance while reducing energy costs.
✔ Eco-Friendly R-32 Refrigerant: Lowers global warming potential and improves efficiency.
✔ Single-Stage Cooling: Ensures steady, reliable temperature control.
✔ Quiet Operation: Designed for minimal noise, improving indoor comfort.
✔ Durable Build: Goodman’s high-quality materials ensure long-lasting performance.
Why Choose Goodman?
Goodman is a renowned HVAC brand, known for providing high-efficiency air conditioning solutions that offer cost savings, durability, and superior cooling performance. The Goodman 4.0 Ton R-32 Cooling System is a great choice for those looking for eco-friendly, high-performance climate control.
📌 Explore more Goodman models:
Goodman R32 Air Conditioners
Goodman Air Conditioners
Product Specification Table
Brand | Goodman |
Model # | GLXS5BA4810 |
SEER2/EER2 | |
Refrigerant | R-32 |
Tonnage | 4.0 Ton |
Coil Type | |
Total Indoor Unit(s) BTU | |
Voltage Requirements | |
Series | |
Coverage Area (Sq. Ft) | |
Indoor Mount Type | |
Indoor Unit BTUs | |
Zone/Rooms | |
AHRI No | GLXS5BA4810 |
Burner Stages | |
Cabinet Width | |
Airflow Direction | |
Furnace Efficiency / AFUE | |
Furnace BTU | |
Power Phase ( Single/Three) | |
Dimensions - (Shipping Unit Width) | 37.00 in |
Dimensions - (Shipping Unit Height) | 38.50 in |
Dimensions - (Shipping Unit Depth) | |
Weight - (Shipping Unit) | 267.090 lb |
Refrigerant Pre-Charged Line Length | 15 ft |
Power Frequency | 60 Hz |
Nom. CFM | |
Motor Speed Type | 0 |
MOCP | |
Min. Circuit Amps | 25.5 A |
Min Voltage | 0 |
Max Voltage | 0 |
Max Overcurrent Protection | 40 A |
LoNox | |
Valve Size Suction (O.D.) | 7/8 in |
Valve Size Liquid (O.D.) | 3/8 in |
Liquid Line Size | |
Energy Source | 0 |
Expansion Device | 0 |
Decibels (dBA) | 74.7 dBA |
Compressor Type | Scroll |
Compressor Stages | Single Stage |
Cased vs Uncased | |
Heating Capacity - (Nominal) | 0 |
Cooling Capacity - (Nominal) | 0 |
Airflow Rate High Cooling | |
Function Category | Split Air Conditioner |
Package System Type | |
Air Handler Mount Type System | |
Split System Type | |
Goodman 5.0 Ton Cased Evaporator R-32 Coil with TXV Upflow/Downflow, CAPTA6030D3
Specifications:
All-Aluminum evaporator coil; Optimized for use with R-32 refrigerant, including circuits and manifolds;R-32 sensor designed for the life span of the coil; Factory-installed thermal expansion valves for cooling and heat pump applications; Standardized copper suction tube stub length; Check the flowrator for cooling and heat pump applications. Vertical application; 21" depth for easier attic access; Single front access panel; Foil-faced insulation covers the internal casing to reduce cabinet condensation. Galvanized, leather grain-embossed finish; Rust resistant, thermoplastic drain pan featuring a low water-retention design; DecaBDE-free thermoplastic drain pan with secondary drain connections; Drain pan rails designed to remove and reposition coils with ease without compromising structural integrity; UV-resistant drain pan; AHRI certified; ETL Listed
Product Specification Table
Brand | Goodman |
Model # | CAPTA6030D3 |
SEER2/EER2 | |
Refrigerant | R-32 |
Tonnage | 5.0 Ton |
Coil Type | Upflow/Downflow |
Total Indoor Unit(s) BTU | |
Voltage Requirements | |
Series | |
Coverage Area (Sq. Ft) | |
Indoor Mount Type | |
Indoor Unit BTUs | |
Zone/Rooms | |
AHRI No | CAPTA6030D3 |
Burner Stages | |
Cabinet Width | |
Airflow Direction | Upflow |
Furnace Efficiency / AFUE | |
Furnace BTU | |
Power Phase ( Single/Three) | |
Dimensions - (Shipping Unit Width) | 26.75 in |
Dimensions - (Shipping Unit Height) | 32.25 in |
Dimensions - (Shipping Unit Depth) | |
Weight - (Shipping Unit) | 70 lb |
Refrigerant Pre-Charged Line Length | 0 |
Power Frequency | 0 |
Nom. CFM | |
Motor Speed Type | 0 |
MOCP | |
Min. Circuit Amps | 0 |
Min Voltage | 0 |
Max Voltage | 0 |
Max Overcurrent Protection | 0 |
LoNox | |
Valve Size Suction (O.D.) | 0 |
Valve Size Liquid (O.D.) | 0 |
Liquid Line Size | |
Energy Source | 0 |
Expansion Device | TXV |
Decibels (dBA) | 0 |
Compressor Type | 0 |
Compressor Stages | 0 |
Cased vs Uncased | |
Heating Capacity - (Nominal) | 0 |
Cooling Capacity - (Nominal) | 0 |
Airflow Rate High Cooling | |
Function Category | |
Package System Type | |
Air Handler Mount Type System | |
Split System Type | |
